This is an ink, wash and charcoal map of a section of the Chenango Canal Feeder in Lebanon. It shows the West Branch Feeder, the West Branch of the Chenango River which splits into two channels, and three bridges. In the left corner of the page is a smaller map. It shows an area of the Chenango River Branch that forms a large basin. The basin is fed by both the West Branch Feeder and the Bradley Brook Feeder. The red lines indicate courses and distances. The blue lines indicate canal right-of-way. The map also shows the properties of Ladd and Wheeler, Rufus Tyler, Jabin Armstrong, Samuel Sherrill and Asa Chase.

Identifier
NYSA_A0848-77_MC8_DR1_V17_CHEN2_173

Date Original
1838

Language
English

Source
New York State Archives, A0848-77, Canal System Survey Maps, 1832-1843, Map no. CHEN2-173
