This is an ink, wash and charcoal map of a section of the Champlain Canal in Waterford. The map is split into two views. The first view shows the Upper Sprout of the Mohawk River, a stream and waste weir, a large basin, three bridges, ten buildings including factories and the Road to West Troy. The second view shows the Upper Sprout of the Mohawk River, a factory canal, two bridges, nine buildings and the Road to West Troy. The red lines indicate courses and distances. The blue lines indicate canal right-of-way. The map also shows the properties of J. Van Schoonhoven, Richard Davis, Tickner, Widow Vanderworken and A. Vanderworken.

Identifier
NYSA_A0848-77_MC7_DR13_V13_CHAM2_49

Date Original
1830

Language
English

Source
New York State Archives, A0848-77, Canal System Survey Maps, 1832-1843, Map no. CHAM2-49

Rights
This image is provided for education and research purposes. Rights may be reserved. Responsibility for securing permissions to distribute, publish, reproduce or other use rest with the user. For additional information see our Copyright and Use Statement
